YSI ProSwap Digital Water Quality Meter
Swap one smart sensor for another with the ProSwap digital water quality meter! Featuring built-in temperature and optional depth sensors, ProSwap can transform into whatever you need: a purpose-built turbidity meter or a high-accuracy optical DO meter; a spot sampling pH meter or a profiling conductivity-temperature-depth system. Even beach monitoring for harmful algal blooms is possible with ProSwap!
ProDIGITAL Platform for Enhanced Versatility
Connect any ProDIGITAL integrated probe/cable assembly to the ProSwap handheld or any ProDSS digital water quality sensor to the ProSwap cable. Sensors and cable assemblies are user-replaceable with cable lengths ranging from 1- to 100-meters.
ProDIGITAL Smart Sensors
The ProSwap incorporates smart sensor technology that enables sensors to be automatically recognized by the handheld. Additionally, DIGITAL sensors store calibration data, so probe assemblies can be swapped between handhelds without the need for re-calibration.
Provides Years of Sampling for All Field Conditions
The ProSwap handheld meets the demands of true field work with a rugged, waterproof case (IP-67 rated) and a military-spec (MS) cable connector. Rigorously drop tested from all angles, the handheld features a 3-year warranty, while a 2-year warranty is included with the cable assembly and any sensor variety.
Advanced Data Management
ProSwap includes KorDSS Software, a powerful data management program for easy 2-way communication between the meter and a PC. A unique data backup feature allows for the export of data to a USB flash drive (included) in csv format without having to connect to a computer
ProSwap meter only, cables and sensors sold separately.
Features
- Ergonomic handheld for a comfortable grip
- Easy-to-read color display and backlit keypad
- Large onboard memory with storage capacity for over 100,000 data sets
- Site ID and Data ID tag capabilities for data organization
- Data export directly to USB flash drive (included)
- Single cable design for probe assembly lengths ranging from 1- to 100-meters
- Long-life rechargeable lithium-ion battery that is user-replaceable
- Simple and quick calibration procedures
Specifications
| Calibration | 400 detailed calibration records can be stored and are available to view, download, and print |
|---|---|
| Certification | CEC, CE; RoHS; IP-67; WEEE; FCC; UN Part III, Section 38.3, Test methods for lithium-ion batteries (Class 9) |
| Dimensions | 8.3 cm width x 21.6 cm length x 5.6 cm depth (3.27 in x 8.5 in x 2.21 in) |
| Display | Color, LCD graphic display; 3.9 cm width x 6.5 cm height |
| Languages | English, Spanish, German, French, Italian, Norwegian, Portuguese, Japanese, Chinese (Simplified & Traditional), Korean, Thai |
| Logging Capabilities | Single point or continuous with autostable feature |
| Memory | 100 user-defined sites and 100 user-defined data ID tags; site pictures can be sent to the handheld via KorDSS, > 100,000 data sets |
| Operating Temperature | 0 to 50 °C (32 to 122 °F) |
| Power | Rechargeable lithium-ion battery pack provides ~48 hours with the handheld only; battery recharge time is ~9 hours with the AC power adapter; the instrument can also be powered via AC or external power pack through the USB port |
| Storage Temperature | 0 to 45 °C (32 to 113 °F) with battery installed; 0 to 60 °C (32 to 140 °F) without battery installed |
| USB | Built-in micro USB On-The-Go port for PC connection, recharging/powering the handheld and connecting directly to a USB stick |
| Warranty | 3-year handheld warranty |
| Weight | 567 grams (1.25 lbs) |
Resources:
The ProSwap uses the same manual as the other ProDigital handhelds (ProSolo, single-parameter and ProDSS, multiparameter). While the manual has not yet been updated to reference the ProSwap, please refer to this document for instructions and troubleshooting until such updates can be made.
