Lakos ABV2 Stainless Steel Automatic Purge Valves
The ABV2 purges solids automatically, eliminating manual purging. It also features an electronic circuit that adjusts motor speed to keep cycle time constant, maintaining consistent purge durations. Typical use cases are in HVAC or commercial applications.
Fits the following LAKOS Separators:
- ILB or ILS Separators
- JPX or JPL Industrial Separators
- eJPX Industrial Separators
Specifications:
-
Voltage: 120-240V AC
-
Frequency: 50/60Hz
-
Power Draw: 30-48 VA
-
Current Draw: 0.3-0.2 A 75% Duty Rated
-
Maximum Pressure Rating: 600 PSI @ 176°F (80°C)
-
Valve Open-Close Time: 8 seconds from 0 to 90 degrees.
-
Housing: V0 self-extinguish class techno-polymer, water-tight
-
Protection Level: NEMA 4/4X IP65 IP67 Certifications: CE UL
-
Cover Type: UL 50
-
Ambient Temperature Range: -4 F to 131 F
-
Auxiliary Contact Rating: 1A @ 30VDC/250VAC RESISTIVE
- Protection Against Electrical Shock: Class I
