BONOMI N501S LEVER OPERATED BUTTERFLY VALVE, EPDM SEAT, LUG BODY, STAINLESS STEEL DISC
Manual Lever operated butterfly valve EPDM seat, lug body stainless steel disc.
Standard EPDM Seat, Buna-N or Viton options available.
- Epoxy coated cast iron lug body
- Full port sizes 2'' to 12''
- ISO 5211 direct mounting pad
- EPDM seat
- Temperature Range:
EPDM: -30 to 250° F
Liquid Temperature Range: -20 to 475° F
- Connection: API609 face to face flange
- Floating dual shaft disc design
- NSF Certification (EPDM Only)
- Max. Pressure: 250 psi water (40 to 80° F)
